| Automated functions | Well plate scanning Z-stack Time lapse Multi-point stitching Full focus stitching Auto focus (Image based) |
|---|---|
| Supported labware | Slide glass, Well plate (6 to 384 wells), Petri dish, etc. |
| Imaging method | Fluorescence, Bright-field, Phase contrast |
| Imaging channels | 4 fluorescence and 1 bright-field, Motorized switching |
| Filter Cube | DAPI, GFP, RFP, CY5, CFP, YFP, Cy7, TRITC, etc. Custom filters available |
| Objective lens | 1.25X - 100X (Olympus high-grade lens) |
| Excitation source | High power LED with brightness control |
| Camera | 5M pixels Scientific-grade color camera |
| Image output | 2448x2048 pixels (5M pixels Scientific-grade color image) 24-bit color Tiff, PNG, or JPG Video: MP4 |
| Motorized hardware | XY stage (120x75 mm, Covering full range of well plates) Focus stage (15 mm) Filter changer (4 fluorescence and bright-field) Objective lens revolving turret (6 positons) Condenser (70 mm, 5 positions) |
| Computer / Monitor | External PC / Internal PC (optional) 27” monitor |
| Power | 100-240 VAC, 150 W, 50/60 Hz |
| Size | 36 x 47 x 53 [WxDxH] (cm) |
| Weight | 32 kg |
