| Instant values measurements: Specifications | |
|---|---|
| Measurement range (to be set in the software) | ±2 g (±18 m/s2)
±8 g (±70 m/s2) |
| Output at 0 g | ±25 mg |
| Frequency range | from DC up to 800 Hz |
| Measurements tolerance (non-linearity, intrinsic noise) | 6 % FSO |
| Offset 0 g, additional (caused by temperature fluctuations) | ±0,2 mg/10°C |
| Measurements tolerance (caused by temperature fluctuations) | ± 0,1 % FSO/10°C |
| Interaxial sensitivity | 1 % |
| Sampling rate* | 250, 2500 Hz |
| Technical specifications | |
| Data transfer interface | CAN 2.0 |
| Exchange speed | 100, 300, 1000 kbit/s |
| Perfomance monitoring in real-time mode | Synchronization quality, data quality |
| Measurements reliability control | Sensing element integrity control |
| Operational specifications | |
| Device power | 9 – 24 V |
| Power consumption | 0,5 W |
| Reverse polarity protection | yes |
| Dimensions | 140×56×28 mm |
| Weight | 300 g |
| Operation temperature range | from -40 up to +80 °C |
| Available product versions | Standard (steel package) Explosion-proof** (explosion safety of 0ExiaIICT6 X type) OEM (compound coating) |
| Electromagnetic compatibility EMC | |
| IEC 61000-4-2, ESD | contact 8 kV; air 15 kV |
| IEC 61000-4-4, EFT | power supply 4 kV; signal 2 kV |
| IEC 61000-4-5, Surge | 4000 V |
* Data compression algorithm – delta-coding with the posiibility of flexible data traffic distribution between the CAN-network transducers
** The cost is calculated on individual basis
Interface converter enables synchronization of digital sensors. This allows to observe mutual infuence in various measurement points. Synchronization accuracy at 1000 kbps CAN speed is ±1 µs.
