手持式静脉血管显影仪是专业为静脉血管显影而设计的静脉血管光学显影仪器,它采用xianjin的血管光子成像技术,为静脉注射,静脉血管查找等应用提供清晰静脉图像,广泛用于手术,静脉注射,采血等应用.
手持式静脉血管显影仪广泛用于医院,诊所,家庭医疗保健和急救医疗服务EMS等部门,具有理想的便携性,方便医生携带到现场使用.用于医院部门，手持式静脉血管显影仪在急诊科和特护病房,重症监护室NICU等单位特别有效,能够节省时间快速扎找到血管.
手持式静脉血管显影仪那怎么使用呢？
手持式静脉血管显影仪高清成像和独家DF2（数字领域）的技术，VeinViewer是唯一的静脉的照明灯成像仪，提供了所有患者在整个前，中、后血管接入过程的利益。
投射近红外光被血液吸收并被周围组织反射。信息被实时地捕获、处理和投射到皮肤表面。它提供了病人血液模式的实时精确图像。
Veinviewer**技术，采用AVIN™（活跃的血管影像导航），让你看到15mm深的血液模式和临床相关的10mm深的静脉。Veinviewer ，临床医生可以看到周围静脉分支阀门及实时充值/冲洗血管的监测。通过术前、术中和术后的可视化成像，临床医生可以避免意外穿刺并发症。改进血管通路的整体程序，不要仅仅把它看作一根棍子。
手持式静脉血管显影仪参数规格
| Brightness | Minimum of 5 lumens |
| Weight | 1.6 lbs. (0.7 kg) |
| Dimensions | 11.6" x 4" x 1.7" |
| Power source | Fast-swap lithium ion batteries or AC (outlet) |
| Imaging/focal distance | 12" (30 cm), meets with AST recommendations for safe distance from the sterile field. |
| veinviewer Flex基础配件包包括： |
|
| (2) Fast-swap rechargeable Lithium Ion Batteries | Up to 2 hours continuous run time per battery |
| Battery Charger | Can be powered via AC Power or car charger |
| AC Power Adapter | To be plugged into an outlet, or an ambulance cabin receptacle |
| International Power Adapters | For use in: North America, EU, UK, China, Australia (Brazil adapter available upon request) |
| (2) S-Mounts (Stability Mount + C-Clamp and Super Clamp Systems) | S-Mounts allow for hands-free, Eyes On Patient™ technique |
| (2) Clamps | Clamps allow clinicians to affix S-Mount to: flat surfaces (tables, countertops), or round/square surfaces (bed rails, IV poles) |
| Storage case | For convenient storage of Flex unit |
| Wrist strap | For ease-of-use |
| VeinViewer Flex Connect PC Software | To upgrade your device |
| USB Cable | For connection to VeinViewer Connect PC software |
| VeinViewer In-Service Training Video | Guide for using VeinViewer Flex |
