sealed.
| Electrical Specifications | Frequency Range | 2 GHz to 18 GHz |
| Gain | 5 dBi to 18 dBi | |
| Polarization | Simultaneous Horizontal & Vertical | |
| 3 dB Beamwidth | 60° to 10° Nominal | |
| Typical VSWR Better than | 2.5:1 | |
| Cross Polarization | -20 dB Maximum | |
| Isolation Between Ports | 25 dB Typical | |
| Maximum Power CW | 10 Watts | |
| Phase Tracking Between Ports | ± 17° Maximum | |
| Amplitude Tracking Between Ports | ± 1.3 dB Maximum | |
| RF Coaxial Connectors | SMA Female | |
| Dimensions | Aperture Diameter | 135 mm |
| Overall Length | 300 mm | |
| Weight | 2.75 kg (3.2 kg DP240-AB) | |
